Tungsten Carbide

Tungsten Carbide

Material

Tungsten Carbide

Bore Dia (d)

25.10mm

Bore Dia Tolerance

+0.00 to -0.03mm

Outer Dia (D)

32.10mm

Outer Dia Tolerance

+0.00 to -0.03mm

Width (B)

25mm

Width Tolerance

+0.00 to -0.08mm

Maximum Temperature

950℃

Ovality

0.005mm

Perpendicularity

0.01mm

Concentricity

0.01mm

Parallelism

0.01mm

Applications

Commonly used on high-precision machining, high-pr

RoHS

Compliant

MATERIAL PROPERTIES

Composition

0.92

Density(g/cm3)

14.7

Hardness(Kg/mm2)

89

Bending strength(Mpa)

2610

Ingredients

0.08

Porosity and non-combined carbon

A02 B00 C00

Grain size

1.6

Tungsten Carbide
